THERM-A-GAP Gels T636 Dispensable, Very Low Compression Force, Thermal Gap Fillers

THERM-A-GAP™ T636 Gel is a highly conformable, pre-cured, single- component compound with 2.4 W/m-K Thermal Conductivity.

属性を選択し、製品検索を改善します。
上記のリストから仕様を選択して下さい。
Description
    THERM-A-GAP™ Gels are highly conformable, pre-cured, single- component compounds. The cross-linked gel structure provides superior long term thermal stability and reliable performance. These unique materials result in much lower mechanical stress on delicate components than even the softest gap-filling sheets. They are ideal for filling variable gaps between multiple components and a common heat sink.

    Features / Benefits

    • Dispensable
    • Fully cured
    • Highly conformable at low pressures
    • No refrigeration, mixing or filler settling issues in storage
    • Single dispensable TIM can eliminate multiple pad part sizes/numbers
    • Reworkable

    Typical Applications

    • Automotive electronic control units (ECUs)
    - Engine control
    - Transmission control
    - Braking/traction control
    • Power conversion equipment
    • Power supplies and uninterruptible power supplies
    • Power semiconductors
    • MOSFET arrays with common heat sinks
    • Televisions and consumer electronics

    Chomerics THERM-A-GAPTM Dispensed Thermal Gels Product Attributes T630 / T630G

    • Years of proven reliability in high-volume automotive applications
    • General use material
    • Good thermal performance
    • Lowest deflection force required
    • Minimal stress on components
    • “G” version has 0.010” glass beads as compression stops for electrical isolation

    T636

    • Superior thermal performance
    • Solves the toughest heat transfer problems
    • Low deflection force required
    • Minimal stress on components
    Consult Applications Engineering for
    automated dispensing equipment recommendations
Description

機能特性

熱伝導率 (W/m-K)

2.4

Yellow

流量

8 cc/min

比重

1.2

2 psi 時の変位 (%)

23

フィルム厚さ (mm)

0.38

熱容量 (J/g-K)

0.9

熱膨張の係数 (ppm/K)

400

作動温度 (F)

-67 to 392

絶縁耐力 (VAC/mil)

200

体積抵抗 (ohm-cm)

10^14

1000 kHz 時の誘導率

4

1000 kHz 時の正接

0.003

証明書に対応

UL 94 V-0, RoHS

ガス放出、% TML (% CVCM)

0.49 (0.18)

貯蔵寿命 (月)

18
