Medium Pressure Mobile Pumps - P1 Series

The Parker P1 Series offers variable displacement axial piston pumps for open-circuit mobile applications. Compact, quiet and efficient, P1 pumps deliver a continuous operating pressure of up to 4,060 psi.

Use our configurator to build the right part for your application.
Description
    Engineered for closed-circuit applications, P1 Medium Pressure Mobile Pumps increase productivity and improve the working environment with a robust cradle-bearing design, wide temperature range, full power thru-drive capability and an optional torque limiter. Featuring unique “ripple chamber” technology, P1 pumps minimize pressure pulsations and decrease noise. With lower power consumption and reduced heat, the series ensures reliable performance and efficient control.

    Markets:
    • Mobile
    • Oil & gas
    • Material handling Equipment
    • Agriculture Machinery
    • Construction Equipment
    • Forestry Equipment
    • Other Mobile
    • Turf Equipment
    • Vocational and Municipal Eqpmt
    • Bus & Coach
    • On-Highway Vehicle (Not Bus/Coach)
    • Rail
    • Transit Authority

    Features/Benefits:
    • Increased Productivity
    • Proportional electric controls that provide flow on demand
    • Large stroking pistons for fast, stable response
    • Full power thru-drive capability
    • Improved Reliability
    • Elastomer seals that eliminate gaskets and external leakage
    • Low friction cam and taper-roller shaft bearings
    • Industry-low viscosity capability
    • Design Flexibility
    • Case drain port for horizontal or vertical shaft-up mounting
    • Optional maximum and minimum volume stops
    • End or side inlet and outlet ports
    • Small envelope size
    • Wide range of controls
    • Ease of Use
    • Low noise nine-piston design
    • Hydraulic controls with “no leak” adjustments
    • Fewer parts for easier maintenance

    Applications:
    • Fan Drives
    • Fire Trucks
    • Concrete Pumps
    • Chemical Pump Trailers
    • Backhoes
    • Bulldozer
    • Front Loaders
    • Winches
    • Log Splitters
    • Casing Jacks
    • Cargo Winches
    • Material Grinders/Chippers

    Technical Characteristics:
    • Maximum operating pressure of 280 bar (4,060 psi)
    • Speed range of 600 – 1,800 rpm
    • Available in 7 displacement (cc) options: 18, 28, 45, 60, 75, 100, 140
Description

Performance Characteristics

Body Material

Cast Iron

Case Drain Option

YES

Charge Pump Option

No

Circuit Type

OPEN

Configuration

Single / Tandem / Multiple

Control Method

Presure Limiter | Load Sense | Electronic Control |Unloading |Proportional|Fan Drive

Energy Recovery Capable

YES

Filtration Option

NO

Fluid Type

Standard Hydraulic Fluid

Maximum Displacement (cm3/rev)

140

Maximum Displacement (in3/rev)

8.5

Maximum Flow (gpm)

73

Maximum Flow (lpm)

278

Maximum Fluid Temperature (C)

95

Maximum Fluid Temperature (F)

200

Minimum Fluid Temperature (C)

-40

Minimum Fluid Temperature (F)

-40

Maximum Noise Level (DBA)

87

Maximum Operating Pressure (bar)

280

Maximum Operating Pressure (psi)

4000

Maximum Radial Shaft Load (kg)

N/A

Maximum Radial Shaft Load (lbs)

N/A

Maximum Speed (rpm)

2000

Maximum Viscosity (SUS)

NA

Minimum Viscosity (SUS)

NA

Maximum Weight (KG)

82

Maximum Weight (lbs)

180

Media

Hydraulic / Liquid

Mounting Option

SAE | ISO

Port Connection

SAE | ISO | BSPP

Port Connection Type

FLANGE | STRAIGHT THREADED

Porting Location

Side Ports | Rear Ports | Opposing Ports

Pump Technology

Piston

Pump Type

Variable

Rotation

Clockwise | Counter Clockwise

Sensor Type

NA

Shaft Type

SAE | ISO

Thru-Drive Capability

YES
