Multi-Purpose, ISO 7241 series B Interchange, Hydraulic Quick Couplings - 60 Series

Part #: SSH2-63Y
  • SSH2-63Y - Multi-Purpose, ISO 7241 series B Interchange, Hydraulic Quick Couplings - 60 Series
  • SSH2-63Y - Multi-Purpose, ISO 7241 series B Interchange, Hydraulic Quick Couplings - 60 Series
  • SSH2-63Y - Multi-Purpose, ISO 7241 series B Interchange, Hydraulic Quick Couplings - 60 Series
SSH2-63Y - Multi-Purpose, ISO 7241 series B Interchange, Hydraulic Quick Couplings - 60 Series
60 series 316 stainless steel nipple, ISO 7241-1 series B
View Series Page View Catalog(s)
Share / EmailPrint

Technical Specifications

Specifications Met:ISO 7241-1 Series B
Coupling Half:Male Nipple
Application:General Purpose
Maximum Operating Temperature:204 °C, 400 °F
Maximum Operating Pressure:5000
Product Type:Manual Connect
Body Size (inch):1/4
Minimum Operating Temperature:-26 °C, -15 °F
Body Material:316 Stainless steel
Valve Type:Poppet
Seal Material:Fluorocarbon
Flow Rate:3 gal/min, 11 L/min
Connection Type:Female NPT
Hex Size:0.75 inch
Connection Thread Size (inch):1/4 - 18
Vacuum Pressure Rating:27.4 inch-Hg, -0.9 bar
Valve Material:Stainless Steel 316
Plating Type:n/a
