Fully Fluorinated Fluorocarbon O-Ring, 75 Shore A, Demanding Applications (Prädifa Series V8930-75, Parofluor®)

Fully Fluorinated Fluorocarbon O-Ring, 75 Shore A, Demanding Applications (Prädifa Series V8930-75, Parofluor®)

Where to Buy

FFKM O-ring with excellent high temperature performance in combination with broad chemical applicability, black.

Technical Specifications

  • Polymer Material Options: Perfluoroelastomer (FFKM, ULTRA®, Parofluor®)
  • Trade Name: V8930-75, V8930, Perfluorinated Elastomer (FFKM)
  • Thermal Application Type: Extremely High Temperature (> 400°F), Extremely High Temperature (> 200°C)
  • Minimum Operating Temperature: 5 °F, -15 °C
  • Maximum Operating Temperature: 617 °F, 325 °C
  • Durometer: 75 Shore A
  • For Fluid Type: Broad Range
  • Industry: Chemical Processing
  • Specifications Met: None, AS 528, ISO 3601, BS 1806, BS 4518, JIS B2401, NF T 47-501, SMS 1586
  • Region of Origin: Europe
  • Internally Lubricated: No
  • Color: Black

Full Product Description

The Parker Prädifa perfluoro elastomer Parofluor® V8930-75 is suitable for a wide range of challenging applications.

Special Features:
• Excellent thermal resistance
• Excellent chemical resistance
• Very good mechanical robustness
• Very good long life time

Chemical Resistance to:
• Methy ethyl ketone (MEK)
• Sulphuric acid (concentrated)
• Nitric acid (concentrated)
• Ammonium hydroxide
• Ethylene diamine
• Tetra hydro thiopene (THT)
• Ethylene acrylate
• Methylene acrylate
• Acetone
• Hot steam
• Water
• Acetic acid (1-molar)
• Oxidising media
• Natural gas
• N-methyl-2-pyrrolidone (NMP)

Related Documents

Literature and Reference Materials
Aerospace Reference Guide--5800
O-Ring Guide-- PTD5712
O-Ring Handbook--PTD5705
Parker O-Ring eHandbook
Parker Tracking System and RFID Technology
Compound Data Sheet FFKM V8930
Installation Guidelines for O-Rings--ODE5705
Training
Basic Technical Glossary -- seal technology training
Introduction to Sealing -- seal technology training
Compliance, Certifications & Safety
How to read a test report
Prop 65 General Statement
Product Demos & Tutorials
How to Properly Store and Clean Elastomer Seals
Mixing the right ingredients: Material Development at Parker-Prädifa
Parker Final Exam in Physics / Sealing Systems Put to the Test
Selector Guides
Healthcare and Life Sciences Solutions - Medical Devices Manufacturing Products
Communities, Blogs & Industry Links
O-Rings Knowledge Base
×
View Catalog
Share / Email
Print
Products Inside Diameter (mm) Width (mm)
020211V8930 20.22 3.53
020214V8930 24.99 3.53
020229V8930 59.92 3.53
020269V8930 221.84 3.53
020340V8930 85.09 5.33
060603V8930 50 4
061428V8930 185 4
060106V8930 15 2.5
060894V8930 27 2.5
060216V8930 90 3
061027V8930 24 3
020014V8930 12.42 1.78
020019V8930 20.35 1.78
020112V8930 12.37 2.62
