| Product Type: | Single-Use Sensor |
| Connection Type: | Luer |
| Options: | Non-Gamma-Irradiated |
| Brand: | SciLog |
| Division: | Bioscience and Water Filtration Division |
| Industry: | Pharmaceuticals |
| Application: | Pressure Sensing |
| Technology: | Condition Monitoring |
| Operating Pressure: | -10 to 60 psi, -0.69 to 4.14 bar (gamma irradiated version to be used for vacuum applications) |
| Product Series: | SciPres |
| Operating Temperature: | 0 to 60 °C |
| Accuracy: | ± 3 % of Reading, 0-60 Psi |
| Materials of Construction: | Transfer Tube: Medical Grade Polysulfone
Sensor Gasket: Silicone |
| Specifications Met: | USP Class VI, REACH, RoHS, WEEE |
| Flow Rate: | 1 L/min |
| Ingress Protection Rating: | IP50 |
| Wetted Material: | Animal Derived Component Free (ADCF) |
