Flat Face Hydraulic, Liquid Cooling Universal Quick Disconnect Blindmate Couplings - UQDB Series

Where to Buy

Quick connect, flat face hydraulic couplers for liquid cooling and thermal management applications for electronics, servers and supercomputers. Universal Quick Disconnect Blindmate (UQDB) is based on an OCP, Intel-inspired open specification.

Technical Specifications

Application: Liquid Cooling, Thermal Management
Maximum Operating Pressure: 10.3 bar, 150 psi
Product Type: Push to Connect
Maximum Operating Temperature: 70 °C, 158 °F
Valve Type: Flat Face
Minimum Operating Temperature: 32 °F
Body Size: 1/8", 1/4", 3/8", 1/2" inch
Maximum Flow Rate: 0.55 to 4.7 (Depending on size) gal/min
Connection Type: Male UNF
Body Material: Stainless Steel
Seal Material: EPDM
Hose Inside Diameter: N/A

Safety Warning

Full Product Description

Universal Quick Disconnect Blindmate (UQDB) based on an Intel inspired open specification. Developed in collaboration with Intel Corporation.

Markets:
- Information Technology
- Electronics
- Data Centers
- Supercomputers

Features/Benefits:
- Flush-face valve design prevents any fluid loss and optimum protection of electrical components
- Reduced pressure drop for superior energy efficiency and system performance
- High resistance to vibrations and rotation
- Broad selection of sealing materials compatible with temperature and fluids
- Manufacturing process that eliminates contamination
- Global manufacturing and service capabilities

Applications:
- Liquid cooling
- Thermal Management
- Data Centers
- Supercomputers
- Electronics
- Servers
- Rackable Server Systems
