Directional Control Valve - D1VW Series(AP)

Directional Control Valve - D1VW Series(AP)

Where to Buy

The D1VW in NG06 (CETOP 03) is an on/off valve which provides high functional limits in combination with a very low, energy-saving pressure drop. It is optionally available with soft shift option

Technical Specifications

  • Product Type: Directional spool valve
  • Actuation Type: Solenoid
  • Size: DIN NG06 / CETOP 03 / NFPA D03 nom
  • Interface Type: DIN 24340 A6 / ISO 4401 / CETOP RP 121-H / NFPA D03
  • Maximum Operating Pressure: P, A, B: 350; T: 210(DC), T: 140(AC) bar
  • Maximum Flow Rate: 80 (depending on spool, see shift limits) L/min
  • Connection Type: Connector as per EN 175301-803, solenoid identification as per ISO 9461 (code W)
  • Ingress Protection Rating: IP65 in accordance with EN 60529 (with correctly mounted plug-in connector)
  • Weight: 2.1(2 solenoids), 1.5(1 solenoid) kg
  • Maximum Operating Temperature: 60 °C
  • Minimum Operating Temperature: -25 °C
  • Seal Material: Nitrile, Fluorocarbon
  • Body Material: Gray Iron
Safety Warning

Full Product Description

The directional control valve series D1VW in NG06 (CETOP 03 / NFPA D03) provides high functional limits up to 80 l/min in combination with a very low, energy-saving pressure drop due to optimized flow passages. The maximum pressure is 350 bar.

A wide variety of spools and options allows to design an unlimited number of hydraulic circuits. The D1VW is available with a soft shift option for smooth operation. An additional orifice in the solenoid anchor dampens the shifting time.

Markets:
• Industrial

Features/Benefits:
• Compact, proven design that represents our long-term experience in hydraulics
• Wide range of spools - fits all hydraulic systems
• Shortest lead time - no warehousing necessary
• Optional soft shift option - for smooth operation
• Optional manual override

Applications:
• Suitable for general hydraulic applications

Related Documents

Product Demos & Tutorials
HVS D1VW Solenoid Operated Control Valve Repair
×
View Catalog
Share / Email
Print
Products Spool Code Spool Position Material - Seals Input Voltage Connection Type Product Series
SD1VW001CNJW 001 C - 3 positions, spring offset in position 0, operated in position a or b N - NBR 24 VDC Connector as per EN 175301-803, solenoid identification as per ISO 9461 (code W) S Series
SD1VW001CNKW 001 C - 3 positions, spring offset in position 0, operated in position a or b N - NBR 12 VDC Connector as per EN 175301-803, solenoid identification as per ISO 9461 (code W) S Series
SD1VW001CNTW 001 C - 3 positions, spring offset in position 0, operated in position a or b N - NBR 230V 50Hz / 240V 60Hz Connector as per EN 175301-803, solenoid identification as per ISO 9461 (code W) S Series
SD1VW001CNYW 001 C - 3 positions, spring offset in position 0, operated in position a or b N - NBR 110V 50 Hz / 120V 60 Hz Connector as per EN 175301-803, solenoid identification as per ISO 9461 (code W) S Series
SD1VW001CVJW 001 C - 3 positions, spring offset in position 0, operated in position a or b V - FKM 24 VDC Connector as per EN 175301-803, solenoid identification as per ISO 9461 (code W) S Series
SD1VW001CVKW 001 C - 3 positions, spring offset in position 0, operated in position a or b V - FKM 12 VDC Connector as per EN 175301-803, solenoid identification as per ISO 9461 (code W) S Series
SD1VW001CVTW 001 C - 3 positions, spring offset in position 0, operated in position a or b V - FKM 230V 50Hz / 240V 60Hz Connector as per EN 175301-803, solenoid identification as per ISO 9461 (code W) S Series
SD1VW001CVYW 001 C - 3 positions, spring offset in position 0, operated in position a or b V - FKM 110V 50 Hz / 120V 60 Hz Connector as per EN 175301-803, solenoid identification as per ISO 9461 (code W) S Series
SD1VW001ENJW 001 E - 2 positions, spring offset in position 0, operated in position a N - NBR 24 VDC Connector as per EN 175301-803, solenoid identification as per ISO 9461 (code W) S Series
SD1VW001ENKW 001 E - 2 positions, spring offset in position 0, operated in position a N - NBR 12 VDC Connector as per EN 175301-803, solenoid identification as per ISO 9461 (code W) S Series
SD1VW001ENTW 001 E - 2 positions, spring offset in position 0, operated in position a N - NBR 230V 50Hz / 240V 60Hz Connector as per EN 175301-803, solenoid identification as per ISO 9461 (code W) S Series
SD1VW001EVJW 001 E - 2 positions, spring offset in position 0, operated in position a V - FKM 24 VDC Connector as per EN 175301-803, solenoid identification as per ISO 9461 (code W) S Series
SD1VW001EVKW 001 E - 2 positions, spring offset in position 0, operated in position a V - FKM 12 VDC Connector as per EN 175301-803, solenoid identification as per ISO 9461 (code W) S Series
SD1VW001EVTW 001 E - 2 positions, spring offset in position 0, operated in position a V - FKM 230V 50Hz / 240V 60Hz Connector as per EN 175301-803, solenoid identification as per ISO 9461 (code W) S Series
SD1VW001FNJW 001 F - 2 positions, Spring offset in position b, operated in position 0 N - NBR 24 VDC Connector as per EN 175301-803, solenoid identification as per ISO 9461 (code W) S Series
SD1VW001KNJW 001 K - 2 positions, spring offset in position 0, operated in position b N - NBR 24 VDC Connector as per EN 175301-803, solenoid identification as per ISO 9461 (code W) S Series
SD1VW001MNJW 001 M - 2 positions, Spring offset in position a, operated in position 0 N - NBR 24 VDC Connector as per EN 175301-803, solenoid identification as per ISO 9461 (code W) S Series
SD1VW002CNJW 002 C - 3 positions, spring offset in position 0, operated in position a or b N - NBR 24 VDC Connector as per EN 175301-803, solenoid identification as per ISO 9461 (code W) S Series
SD1VW002CNKW 002 C - 3 positions, spring offset in position 0, operated in position a or b N - NBR 12 VDC Connector as per EN 175301-803, solenoid identification as per ISO 9461 (code W) S Series
SD1VW002CNTW 002 C - 3 positions, spring offset in position 0, operated in position a or b N - NBR 230V 50Hz / 240V 60Hz Connector as per EN 175301-803, solenoid identification as per ISO 9461 (code W) S Series
SD1VW002CNYW 002 C - 3 positions, spring offset in position 0, operated in position a or b N - NBR 110V 50 Hz / 120V 60 Hz Connector as per EN 175301-803, solenoid identification as per ISO 9461 (code W) S Series
SD1VW002CVJW 002 C - 3 positions, spring offset in position 0, operated in position a or b V - FKM 24 VDC Connector as per EN 175301-803, solenoid identification as per ISO 9461 (code W) S Series
SD1VW002CVKW 002 C - 3 positions, spring offset in position 0, operated in position a or b V - FKM 12 VDC Connector as per EN 175301-803, solenoid identification as per ISO 9461 (code W) S Series
SD1VW002CVTW 002 C - 3 positions, spring offset in position 0, operated in position a or b V - FKM 230V 50Hz / 240V 60Hz Connector as per EN 175301-803, solenoid identification as per ISO 9461 (code W) S Series
SD1VW002CVYW 002 C - 3 positions, spring offset in position 0, operated in position a or b V - FKM 110V 50 Hz / 120V 60 Hz Connector as per EN 175301-803, solenoid identification as per ISO 9461 (code W) S Series
SD1VW002ENJW 002 E - 2 positions, spring offset in position 0, operated in position a N - NBR 24 VDC Connector as per EN 175301-803, solenoid identification as per ISO 9461 (code W) S Series
SD1VW002ENKW 002 E - 2 positions, spring offset in position 0, operated in position a N - NBR 12 VDC Connector as per EN 175301-803, solenoid identification as per ISO 9461 (code W) S Series
SD1VW002ENTW 002 E - 2 positions, spring offset in position 0, operated in position a N - NBR 230V 50Hz / 240V 60Hz Connector as per EN 175301-803, solenoid identification as per ISO 9461 (code W) S Series
SD1VW002EVJW 002 E - 2 positions, spring offset in position 0, operated in position a V - FKM 24 VDC Connector as per EN 175301-803, solenoid identification as per ISO 9461 (code W) S Series
SD1VW002EVKW 002 E - 2 positions, spring offset in position 0, operated in position a V - FKM 12 VDC Connector as per EN 175301-803, solenoid identification as per ISO 9461 (code W) S Series
SD1VW002EVTW 002 E - 2 positions, spring offset in position 0, operated in position a V - FKM 230V 50Hz / 240V 60Hz Connector as per EN 175301-803, solenoid identification as per ISO 9461 (code W) S Series
SD1VW002FNJW 002 F - 2 positions, Spring offset in position b, operated in position 0 N - NBR 24 VDC Connector as per EN 175301-803, solenoid identification as per ISO 9461 (code W) S Series
SD1VW002KNJW 002 K - 2 positions, spring offset in position 0, operated in position b N - NBR 24 VDC Connector as per EN 175301-803, solenoid identification as per ISO 9461 (code W) S Series
SD1VW002MNJW 002 M - 2 positions, Spring offset in position a, operated in position 0 N - NBR 24 VDC Connector as per EN 175301-803, solenoid identification as per ISO 9461 (code W) S Series
SD1VW004CNJW 004 C - 3 positions, spring offset in position 0, operated in position a or b N - NBR 24 VDC Connector as per EN 175301-803, solenoid identification as per ISO 9461 (code W) S Series
SD1VW004CNKW 004 C - 3 positions, spring offset in position 0, operated in position a or b N - NBR 12 VDC Connector as per EN 175301-803, solenoid identification as per ISO 9461 (code W) S Series
SD1VW004CNTW 004 C - 3 positions, spring offset in position 0, operated in position a or b N - NBR 230V 50Hz / 240V 60Hz Connector as per EN 175301-803, solenoid identification as per ISO 9461 (code W) S Series
SD1VW004CNYW 004 C - 3 positions, spring offset in position 0, operated in position a or b N - NBR 110V 50 Hz / 120V 60 Hz Connector as per EN 175301-803, solenoid identification as per ISO 9461 (code W) S Series
SD1VW004CVJW 004 C - 3 positions, spring offset in position 0, operated in position a or b V - FKM 24 VDC Connector as per EN 175301-803, solenoid identification as per ISO 9461 (code W) S Series
SD1VW004CVKW 004 C - 3 positions, spring offset in position 0, operated in position a or b V - FKM 12 VDC Connector as per EN 175301-803, solenoid identification as per ISO 9461 (code W) S Series
SD1VW004CVTW 004 C - 3 positions, spring offset in position 0, operated in position a or b V - FKM 230V 50Hz / 240V 60Hz Connector as per EN 175301-803, solenoid identification as per ISO 9461 (code W) S Series
SD1VW004CVYW 004 C - 3 positions, spring offset in position 0, operated in position a or b V - FKM 110V 50 Hz / 120V 60 Hz Connector as per EN 175301-803, solenoid identification as per ISO 9461 (code W) S Series
SD1VW004ENJW 004 E - 2 positions, spring offset in position 0, operated in position a N - NBR 24 VDC Connector as per EN 175301-803, solenoid identification as per ISO 9461 (code W) S Series
SD1VW004KNJW 004 K - 2 positions, spring offset in position 0, operated in position b N - NBR 24 VDC Connector as per EN 175301-803, solenoid identification as per ISO 9461 (code W) S Series
SD1VW004EVJW 004 E - 2 positions, spring offset in position 0, operated in position a V - FKM 24 VDC Connector as per EN 175301-803, solenoid identification as per ISO 9461 (code W) S Series
SD1VW004KVJW 004 K - 2 positions, spring offset in position 0, operated in position b V - FKM 24 VDC Connector as per EN 175301-803, solenoid identification as per ISO 9461 (code W) S Series
SD1VW006CNJW 006 C - 3 positions, spring offset in position 0, operated in position a or b N - NBR 24 VDC Connector as per EN 175301-803, solenoid identification as per ISO 9461 (code W) S Series
SD1VW006CVJW 006 C - 3 positions, spring offset in position 0, operated in position a or b V - FKM 24 VDC Connector as per EN 175301-803, solenoid identification as per ISO 9461 (code W) S Series
SD1VW006KNJW 006 K - 2 positions, spring offset in position 0, operated in position b N - NBR 24 VDC Connector as per EN 175301-803, solenoid identification as per ISO 9461 (code W) S Series
SD1VW006KVJW 006 K - 2 positions, spring offset in position 0, operated in position b V - FKM 24 VDC Connector as per EN 175301-803, solenoid identification as per ISO 9461 (code W) S Series
SD1VW008CNJW 008 C - 3 positions, spring offset in position 0, operated in position a or b N - NBR 24 VDC Connector as per EN 175301-803, solenoid identification as per ISO 9461 (code W) S Series
SD1VW008CNKW 008 C - 3 positions, spring offset in position 0, operated in position a or b N - NBR 12 VDC Connector as per EN 175301-803, solenoid identification as per ISO 9461 (code W) S Series
SD1VW008CNTW 008 C - 3 positions, spring offset in position 0, operated in position a or b N - NBR 230V 50Hz / 240V 60Hz Connector as per EN 175301-803, solenoid identification as per ISO 9461 (code W) S Series
SD1VW008CNYW 008 C - 3 positions, spring offset in position 0, operated in position a or b N - NBR 110V 50 Hz / 120V 60 Hz Connector as per EN 175301-803, solenoid identification as per ISO 9461 (code W) S Series
SD1VW008CVJW 008 C - 3 positions, spring offset in position 0, operated in position a or b V - FKM 24 VDC Connector as per EN 175301-803, solenoid identification as per ISO 9461 (code W) S Series
SD1VW008CVKW 008 C - 3 positions, spring offset in position 0, operated in position a or b V - FKM 12 VDC Connector as per EN 175301-803, solenoid identification as per ISO 9461 (code W) S Series
SD1VW008CVTW 008 C - 3 positions, spring offset in position 0, operated in position a or b V - FKM 230V 50Hz / 240V 60Hz Connector as per EN 175301-803, solenoid identification as per ISO 9461 (code W) S Series
SD1VW008CVYW 008 C - 3 positions, spring offset in position 0, operated in position a or b V - FKM 110V 50 Hz / 120V 60 Hz Connector as per EN 175301-803, solenoid identification as per ISO 9461 (code W) S Series
SD1VW008ENJW 008 E - 2 positions, spring offset in position 0, operated in position b N - NBR 24 VDC Connector as per EN 175301-803, solenoid identification as per ISO 9461 (code W) S Series
SD1VW008FNJW 008 F - 2 positions, spring offset in position a, operated in position 0 N - NBR 24 VDC Connector as per EN 175301-803, solenoid identification as per ISO 9461 (code W) S Series
SD1VW008KNJW 008 K - 2 positions, spring offset in position 0, operated in position a N - NBR 24 VDC Connector as per EN 175301-803, solenoid identification as per ISO 9461 (code W) S Series
SD1VW008EVJW 008 E - 2 positions, spring offset in position 0, operated in position b V - FKM 24 VDC Connector as per EN 175301-803, solenoid identification as per ISO 9461 (code W) S Series
SD1VW008FVJW 008 F - 2 positions, spring offset in position a, operated in position 0 V - FKM 24 VDC Connector as per EN 175301-803, solenoid identification as per ISO 9461 (code W) S Series
SD1VW008KVJW 008 K - 2 positions, spring offset in position 0, operated in position a V - FKM 24 VDC Connector as per EN 175301-803, solenoid identification as per ISO 9461 (code W) S Series
SD1VW009CNJW 009 C - 3 positions, spring offset in position 0, operated in position a or b N - NBR 24 VDC Connector as per EN 175301-803, solenoid identification as per ISO 9461 (code W) S Series
SD1VW009KNJW 009 K - 2 positions, spring offset in position 0, operated in position a N - NBR 24 VDC Connector as per EN 175301-803, solenoid identification as per ISO 9461 (code W) S Series
SD1VW009CVJW 009 C - 3 positions, spring offset in position 0, operated in position a or b V - FKM 24 VDC Connector as per EN 175301-803, solenoid identification as per ISO 9461 (code W) S Series
SD1VW009KVJW 009 K - 2 positions, spring offset in position 0, operated in position a V - FKM 24 VDC Connector as per EN 175301-803, solenoid identification as per ISO 9461 (code W) S Series
SD1VW011CNJW 011 C - 3 positions, spring offset in position 0, operated in position a or b N - NBR 24 VDC Connector as per EN 175301-803, solenoid identification as per ISO 9461 (code W) S Series
SD1VW011CVJW 011 C - 3 positions, spring offset in position 0, operated in position a or b V - FKM 24 VDC Connector as per EN 175301-803, solenoid identification as per ISO 9461 (code W) S Series
SD1VW020BNJW 020 B - 2 positions, spring offset in position b, operated in position a N - NBR 24 VDC Connector as per EN 175301-803, solenoid identification as per ISO 9461 (code W) S Series
SD1VW020BNKW 020 B - 2 positions, spring offset in position b, operated in position a N - NBR 12 VDC Connector as per EN 175301-803, solenoid identification as per ISO 9461 (code W) S Series
SD1VW020BNTW 020 B - 2 positions, spring offset in position b, operated in position a N - NBR 230V 50Hz / 240V 60Hz Connector as per EN 175301-803, solenoid identification as per ISO 9461 (code W) S Series
SD1VW020BNYW 020 B - 2 positions, spring offset in position b, operated in position a N - NBR 110V 50 Hz / 120V 60 Hz Connector as per EN 175301-803, solenoid identification as per ISO 9461 (code W) S Series
SD1VW020BVJW 020 B - 2 positions, spring offset in position b, operated in position a V - FKM 24 VDC Connector as per EN 175301-803, solenoid identification as per ISO 9461 (code W) S Series
SD1VW020BVKW 020 B - 2 positions, spring offset in position b, operated in position a V - FKM 12 VDC Connector as per EN 175301-803, solenoid identification as per ISO 9461 (code W) S Series
SD1VW020BVTW 020 B - 2 positions, spring offset in position b, operated in position a V - FKM 230V 50Hz / 240V 60Hz Connector as per EN 175301-803, solenoid identification as per ISO 9461 (code W) S Series
SD1VW020BVYW 020 B - 2 positions, spring offset in position b, operated in position a V - FKM 110V 50 Hz / 120V 60 Hz Connector as per EN 175301-803, solenoid identification as per ISO 9461 (code W) S Series
SD1VW020DNJW 020 D - 2 positions, operated in position a or b, no center or offset position N - NBR 24 VDC Connector as per EN 175301-803, solenoid identification as per ISO 9461 (code W) S Series
SD1VW020DNTW 020 D - 2 positions, operated in position a or b, no center or offset position N - NBR 230V 50Hz / 240V 60Hz Connector as per EN 175301-803, solenoid identification as per ISO 9461 (code W) S Series
SD1VW020DNYW 020 D - 2 positions, operated in position a or b, no center or offset position N - NBR 110V 50 Hz / 120V 60 Hz Connector as per EN 175301-803, solenoid identification as per ISO 9461 (code W) S Series
SD1VW020DVJW 020 D - 2 positions, operated in position a or b, no center or offset position V - FKM 24 VDC Connector as per EN 175301-803, solenoid identification as per ISO 9461 (code W) S Series
SD1VW020DVTW 020 D - 2 positions, operated in position a or b, no center or offset position V - FKM 230V 50Hz / 240V 60Hz Connector as per EN 175301-803, solenoid identification as per ISO 9461 (code W) S Series
SD1VW020DVYW 020 D - 2 positions, operated in position a or b, no center or offset position V - FKM 110V 50 Hz / 120V 60 Hz Connector as per EN 175301-803, solenoid identification as per ISO 9461 (code W) S Series
SD1VW020HNJW 020 H - 2 positions, spring offset in position a, operated in position b N - NBR 24 VDC Connector as per EN 175301-803, solenoid identification as per ISO 9461 (code W) S Series
SD1VW020HVJW 020 H - 2 positions, spring offset in position a, operated in position b V - FKM 24 VDC Connector as per EN 175301-803, solenoid identification as per ISO 9461 (code W) S Series
SD1VW020HNTW 020 H - 2 positions, spring offset in position a, operated in position b N - NBR 230V 50Hz / 240V 60Hz Connector as per EN 175301-803, solenoid identification as per ISO 9461 (code W) S Series
SD1VW020HNYW 020 H - 2 positions, spring offset in position a, operated in position b N - NBR 110V 50 Hz / 120V 60 Hz Connector as per EN 175301-803, solenoid identification as per ISO 9461 (code W) S Series
SD1VW022CNJW 022 C - 3 positions, spring offset in position 0, operated in position a or b N - NBR 24 VDC Connector as per EN 175301-803, solenoid identification as per ISO 9461 (code W) S Series
SD1VW026BNJW 026 B - 2 positions, spring offset in position b, operated in position a N - NBR 24 VDC Connector as per EN 175301-803, solenoid identification as per ISO 9461 (code W) S Series
SD1VW026BVJW 026 B - 2 positions, spring offset in position b, operated in position a V - FKM 24 VDC Connector as per EN 175301-803, solenoid identification as per ISO 9461 (code W) S Series
SD1VW030BNJW 030 B - 2 positions, spring offset in position b, operated in position a N - NBR 24 VDC Connector as per EN 175301-803, solenoid identification as per ISO 9461 (code W) S Series
SD1VW030BNTW 030 B - 2 positions, spring offset in position b, operated in position a N - NBR 230V 50Hz / 240V 60Hz Connector as per EN 175301-803, solenoid identification as per ISO 9461 (code W) S Series
SD1VW030BVJW 030 B - 2 positions, spring offset in position b, operated in position a V - FKM 24 VDC Connector as per EN 175301-803, solenoid identification as per ISO 9461 (code W) S Series
SD1VW030BVTW 030 B - 2 positions, spring offset in position b, operated in position a V - FKM 230V 50Hz / 240V 60Hz Connector as per EN 175301-803, solenoid identification as per ISO 9461 (code W) S Series
SD1VW001CNJJ 001 C - 3 positions, spring offset in position 0, operated in position a or b N - NBR 24 VDC Connector as DT04-2P “Deutsch" (code J) S Series
SD1VW001KVJW 001 K - 2 positions, spring offset in position 0, operated in position b V - FKM 24 VDC Connector as per EN 175301-803, solenoid identification as per ISO 9461 (code W) S Series
SD1VW003CNJW 003 C - 3 positions, spring offset in position 0, operated in position a or b N - NBR 24 VDC Connector as per EN 175301-803, solenoid identification as per ISO 9461 (code W) S Series
SD1VW004FNJW 004 F - 2 positions, Spring offset in position b, operated in position 0 N - NBR 24 VDC Connector as per EN 175301-803, solenoid identification as per ISO 9461 (code W) S Series
SD1VW006ENJW 006 E - 2 positions, spring offset in position 0, operated in position a N - NBR 24 VDC Connector as per EN 175301-803, solenoid identification as per ISO 9461 (code W) S Series
SD1VW009CNKW 009 C - 3 positions, spring offset in position 0, operated in position a or b N - NBR 12 VDC Connector as per EN 175301-803, solenoid identification as per ISO 9461 (code W) S Series
SD1VW010CNJW 010 C - 3 positions, spring offset in position 0, operated in position a or b N - NBR 24 VDC Connector as per EN 175301-803, solenoid identification as per ISO 9461 (code W) S Series
SD1VW015CNJW 015 C - 3 positions, spring offset in position 0, operated in position a or b N - NBR 24 VDC Connector as per EN 175301-803, solenoid identification as per ISO 9461 (code W) S Series
SD1VW020DNKW 020 D - 2 positions, operated in position a or b, no center or offset position N - NBR 12 VDC Connector as per EN 175301-803, solenoid identification as per ISO 9461 (code W) S Series
SD1VW026HNJW 026 H - 2 positions, spring offset in position a, operated in position b N - NBR 24 VDC Connector as per EN 175301-803, solenoid identification as per ISO 9461 (code W) S Series
SD1VW026HVJW 026 H - 2 positions, spring offset in position a, operated in position b V - FKM 24 VDC Connector as per EN 175301-803, solenoid identification as per ISO 9461 (code W) S Series
SD1VW030HNJW 030 H - 2 positions, spring offset in position a, operated in position b N - NBR 24 VDC Connector as per EN 175301-803, solenoid identification as per ISO 9461 (code W) S Series
SD1VW034CNJW 034 C - 3 positions, spring offset in position 0, operated in position a or b N - NBR 24 VDC Connector as per EN 175301-803, solenoid identification as per ISO 9461 (code W) S Series
D1VW001CNKWXC005 001 C - 3 positions, spring offset in position 0, operated in position a or b N - NBR 12 VDC Connector as per EN 175301-803, solenoid identification as per ISO 9461 (code W) XC005
D1VW001CVJWXC005 001 C - 3 positions, spring offset in position 0, operated in position a or b V - FKM 24 VDC Connector as per EN 175301-803, solenoid identification as per ISO 9461 (code W) XC005
D1VW001ENKWXC005 001 E - 2 positions, spring offset in position 0, operated in position a N - NBR 12 VDC Connector as per EN 175301-803, solenoid identification as per ISO 9461 (code W) XC005
D1VW001KNJWXC005 001 K - 2 positions, spring offset in position 0, operated in position b N - NBR 24 VDC Connector as per EN 175301-803, solenoid identification as per ISO 9461 (code W) XC005
D1VW001KNKWXC005 001 K - 2 positions, spring offset in position 0, operated in position b N - NBR 12 VDC Connector as per EN 175301-803, solenoid identification as per ISO 9461 (code W) XC005
D1VW002CNKWXC005 002 C - 3 positions, spring offset in position 0, operated in position a or b N - NBR 12 VDC Connector as per EN 175301-803, solenoid identification as per ISO 9461 (code W) XC005
D1VW002CVJWXC005 002 C - 3 positions, spring offset in position 0, operated in position a or b V - FKM 24 VDC Connector as per EN 175301-803, solenoid identification as per ISO 9461 (code W) XC005
D1VW002ENKWXC005 002 E - 2 positions, spring offset in position 0, operated in position a N - NBR 12 VDC Connector as per EN 175301-803, solenoid identification as per ISO 9461 (code W) XC005
D1VW002KNJWXC005 002 K - 2 positions, spring offset in position 0, operated in position b N - NBR 24 VDC Connector as per EN 175301-803, solenoid identification as per ISO 9461 (code W) XC005
D1VW002KNKWXC005 002 K - 2 positions, spring offset in position 0, operated in position b N - NBR 12 VDC Connector as per EN 175301-803, solenoid identification as per ISO 9461 (code W) XC005
D1VW003CNJWXC005 003 C - 3 positions, spring offset in position 0, operated in position a or b N - NBR 24 VDC Connector as per EN 175301-803, solenoid identification as per ISO 9461 (code W) XC005
D1VW003KNJWXC005 003 K - 2 positions, spring offset in position 0, operated in position b N - NBR 24 VDC Connector as per EN 175301-803, solenoid identification as per ISO 9461 (code W) XC005
D1VW004CNKWXC005 004 C - 3 positions, spring offset in position 0, operated in position a or b N - NBR 12 VDC Connector as per EN 175301-803, solenoid identification as per ISO 9461 (code W) XC005
D1VW004CVJWXC005 004 C - 3 positions, spring offset in position 0, operated in position a or b V - FKM 24 VDC Connector as per EN 175301-803, solenoid identification as per ISO 9461 (code W) XC005
D1VW004ENJWXC005 004 E - 2 positions, spring offset in position 0, operated in position a N - NBR 24 VDC Connector as per EN 175301-803, solenoid identification as per ISO 9461 (code W) XC005
D1VW004ENKWXC005 004 E - 2 positions, spring offset in position 0, operated in position a N - NBR 12 VDC Connector as per EN 175301-803, solenoid identification as per ISO 9461 (code W) XC005
D1VW004KNJWXC005 004 K - 2 positions, spring offset in position 0, operated in position b N - NBR 24 VDC Connector as per EN 175301-803, solenoid identification as per ISO 9461 (code W) XC005
D1VW004KNKWXC005 004 K - 2 positions, spring offset in position 0, operated in position b N - NBR 12 VDC Connector as per EN 175301-803, solenoid identification as per ISO 9461 (code W) XC005
D1VW006CNJWXC005 006 C - 3 positions, spring offset in position 0, operated in position a or b N - NBR 24 VDC Connector as per EN 175301-803, solenoid identification as per ISO 9461 (code W) XC005
D1VW006CNKWXC005 006 C - 3 positions, spring offset in position 0, operated in position a or b N - NBR 12 VDC Connector as per EN 175301-803, solenoid identification as per ISO 9461 (code W) XC005
D1VW006CVJWXC005 006 C - 3 positions, spring offset in position 0, operated in position a or b V - FKM 24 VDC Connector as per EN 175301-803, solenoid identification as per ISO 9461 (code W) XC005
D1VW006ENJWXC005 006 E - 2 positions, spring offset in position 0, operated in position a N - NBR 24 VDC Connector as per EN 175301-803, solenoid identification as per ISO 9461 (code W) XC005
D1VW006ENKWXC005 006 E - 2 positions, spring offset in position 0, operated in position a N - NBR 12 VDC Connector as per EN 175301-803, solenoid identification as per ISO 9461 (code W) XC005
D1VW006KNJWXC005 006 K - 2 positions, spring offset in position 0, operated in position b N - NBR 24 VDC Connector as per EN 175301-803, solenoid identification as per ISO 9461 (code W) XC005
D1VW006KNKWXC005 006 K - 2 positions, spring offset in position 0, operated in position b N - NBR 12 VDC Connector as per EN 175301-803, solenoid identification as per ISO 9461 (code W) XC005
D1VW008CVJWXC005 008 C - 3 positions, spring offset in position 0, operated in position a or b V - FKM 24 VDC Connector as per EN 175301-803, solenoid identification as per ISO 9461 (code W) XC005
D1VW008ENKWXC005 008 E - 2 positions, spring offset in position 0, operated in position a N - NBR 12 VDC Connector as per EN 175301-803, solenoid identification as per ISO 9461 (code W) XC005
D1VW008EVJWXC005 008 E - 2 positions, spring offset in position 0, operated in position a V - FKM 24 VDC Connector as per EN 175301-803, solenoid identification as per ISO 9461 (code W) XC005
D1VW008KNJWXC005 008 K - 2 positions, spring offset in position 0, operated in position b N - NBR 24 VDC Connector as per EN 175301-803, solenoid identification as per ISO 9461 (code W) XC005
D1VW009CNJWXC005 009 C - 3 positions, spring offset in position 0, operated in position a or b N - NBR 24 VDC Connector as per EN 175301-803, solenoid identification as per ISO 9461 (code W) XC005
D1VW009CVJWXC005 009 C - 3 positions, spring offset in position 0, operated in position a or b V - FKM 24 VDC Connector as per EN 175301-803, solenoid identification as per ISO 9461 (code W) XC005
D1VW009ENJWXC005 009 E - 2 positions, spring offset in position 0, operated in position a N - NBR 24 VDC Connector as per EN 175301-803, solenoid identification as per ISO 9461 (code W) XC005
D1VW009ENKWXC005 009 E - 2 positions, spring offset in position 0, operated in position a N - NBR 12 VDC Connector as per EN 175301-803, solenoid identification as per ISO 9461 (code W) XC005
D1VW009EVJWXC005 009 E - 2 positions, spring offset in position 0, operated in position a V - FKM 24 VDC Connector as per EN 175301-803, solenoid identification as per ISO 9461 (code W) XC005
D1VW009KNJWXC005 009 K - 2 positions, spring offset in position 0, operated in position b N - NBR 24 VDC Connector as per EN 175301-803, solenoid identification as per ISO 9461 (code W) XC005
D1VW011CNJWXC005 011 C - 3 positions, spring offset in position 0, operated in position a or b N - NBR 24 VDC Connector as per EN 175301-803, solenoid identification as per ISO 9461 (code W) XC005
D1VW011CNKWXC005 011 C - 3 positions, spring offset in position 0, operated in position a or b N - NBR 12 VDC Connector as per EN 175301-803, solenoid identification as per ISO 9461 (code W) XC005
D1VW011CVJWXC005 011 C - 3 positions, spring offset in position 0, operated in position a or b V - FKM 24 VDC Connector as per EN 175301-803, solenoid identification as per ISO 9461 (code W) XC005
D1VW014CNJWXC005 014 C - 3 positions, spring offset in position 0, operated in position a or b N - NBR 24 VDC Connector as per EN 175301-803, solenoid identification as per ISO 9461 (code W) XC005
D1VW015CNJWXC005 015 C - 3 positions, spring offset in position 0, operated in position a or b N - NBR 24 VDC Connector as per EN 175301-803, solenoid identification as per ISO 9461 (code W) XC005
D1VW015KNJWXC005 015 K - 2 positions, spring offset in position 0, operated in position b N - NBR 24 VDC Connector as per EN 175301-803, solenoid identification as per ISO 9461 (code W) XC005
D1VW020DNJWXC005 020 D - 2 positions, operated in position a or b, no center or offset position N - NBR 24 VDC Connector as per EN 175301-803, solenoid identification as per ISO 9461 (code W) XC005
D1VW020HNKWXC005 020 H - 2 positions, spring offset in position a, operated in position b N - NBR 12 VDC Connector as per EN 175301-803, solenoid identification as per ISO 9461 (code W) XC005
D1VW026BNJWXC005 026 B - 2 positions, spring offset in position b, operated in position a N - NBR 24 VDC Connector as per EN 175301-803, solenoid identification as per ISO 9461 (code W) XC005
D1VW026BNKWXC005 026 B - 2 positions, spring offset in position b, operated in position a N - NBR 12 VDC Connector as per EN 175301-803, solenoid identification as per ISO 9461 (code W) XC005
D1VW026HNJWXC005 026 H - 2 positions, spring offset in position a, operated in position b N - NBR 24 VDC Connector as per EN 175301-803, solenoid identification as per ISO 9461 (code W) XC005
D1VW026HNKWXC005 026 H - 2 positions, spring offset in position a, operated in position b N - NBR 12 VDC Connector as per EN 175301-803, solenoid identification as per ISO 9461 (code W) XC005
D1VW030BNKWXC005 030 B - 2 positions, spring offset in position b, operated in position a N - NBR 12 VDC Connector as per EN 175301-803, solenoid identification as per ISO 9461 (code W) XC005
D1VW030HNJWXC005 030 H - 2 positions, spring offset in position a, operated in position b N - NBR 24 VDC Connector as per EN 175301-803, solenoid identification as per ISO 9461 (code W) XC005
D1VW030HNKWXC005 030 H - 2 positions, spring offset in position a, operated in position b N - NBR 12 VDC Connector as per EN 175301-803, solenoid identification as per ISO 9461 (code W) XC005
SD1VW001FNTW 001 F - 2 positions, Spring offset in position b, operated in position 0 N - NBR 230V 50Hz / 240V 60Hz Connector as per EN 175301-803, solenoid identification as per ISO 9461 (code W) S Series
SD1VW001FVJW 001 F - 2 positions, Spring offset in position b, operated in position 0 V - FKM 24 VDC Connector as per EN 175301-803, solenoid identification as per ISO 9461 (code W) S Series
SD1VW001KNTW 001 K - 2 positions, spring offset in position 0, operated in position b N - NBR 230V 50Hz / 240V 60Hz Connector as per EN 175301-803, solenoid identification as per ISO 9461 (code W) S Series
SD1VW001KNYW 001 K - 2 positions, spring offset in position 0, operated in position b N - NBR 110V 50 Hz / 120V 60 Hz Connector as per EN 175301-803, solenoid identification as per ISO 9461 (code W) S Series
SD1VW002ENYW 002 E - 2 positions, spring offset in position 0, operated in position a N - NBR 110V 50 Hz / 120V 60 Hz Connector as per EN 175301-803, solenoid identification as per ISO 9461 (code W) S Series
SD1VW002FNYW 002 F - 2 positions, Spring offset in position b, operated in position 0 N - NBR 110V 50 Hz / 120V 60 Hz Connector as per EN 175301-803, solenoid identification as per ISO 9461 (code W) S Series
SD1VW002KNKW 002 K - 2 positions, spring offset in position 0, operated in position b N - NBR 12 VDC Connector as per EN 175301-803, solenoid identification as per ISO 9461 (code W) S Series
SD1VW002KNTW 002 K - 2 positions, spring offset in position 0, operated in position b N - NBR 230V 50Hz / 240V 60Hz Connector as per EN 175301-803, solenoid identification as per ISO 9461 (code W) S Series
SD1VW002KNYW 002 K - 2 positions, spring offset in position 0, operated in position b N - NBR 110V 50 Hz / 120V 60 Hz Connector as per EN 175301-803, solenoid identification as per ISO 9461 (code W) S Series
SD1VW002KVJW 002 K - 2 positions, spring offset in position 0, operated in position b V - FKM 24 VDC Connector as per EN 175301-803, solenoid identification as per ISO 9461 (code W) S Series
SD1VW003KNJW 003 K - 2 positions, spring offset in position 0, operated in position b N - NBR 24 VDC Connector as per EN 175301-803, solenoid identification as per ISO 9461 (code W) S Series
SD1VW004ENTW 004 E - 2 positions, spring offset in position 0, operated in position a N - NBR 230V 50Hz / 240V 60Hz Connector as per EN 175301-803, solenoid identification as per ISO 9461 (code W) S Series
SD1VW004KNKW 004 K - 2 positions, spring offset in position 0, operated in position b N - NBR 12 VDC Connector as per EN 175301-803, solenoid identification as per ISO 9461 (code W) S Series
SD1VW004KNTW 004 K - 2 positions, spring offset in position 0, operated in position b N - NBR 230V 50Hz / 240V 60Hz Connector as per EN 175301-803, solenoid identification as per ISO 9461 (code W) S Series
SD1VW004KNYW 004 K - 2 positions, spring offset in position 0, operated in position b N - NBR 110V 50 Hz / 120V 60 Hz Connector as per EN 175301-803, solenoid identification as per ISO 9461 (code W) S Series
SD1VW005CNJW 005 C - 3 positions, spring offset in position 0, operated in position a or b N - NBR 24 VDC Connector as per EN 175301-803, solenoid identification as per ISO 9461 (code W) S Series
SD1VW005KNJW 005 K - 2 positions, spring offset in position 0, operated in position b N - NBR 24 VDC Connector as per EN 175301-803, solenoid identification as per ISO 9461 (code W) S Series
SD1VW006CNTW 006 C - 3 positions, spring offset in position 0, operated in position a or b N - NBR 230V 50Hz / 240V 60Hz Connector as per EN 175301-803, solenoid identification as per ISO 9461 (code W) S Series
SD1VW006CNYW 006 C - 3 positions, spring offset in position 0, operated in position a or b N - NBR 110V 50 Hz / 120V 60 Hz Connector as per EN 175301-803, solenoid identification as per ISO 9461 (code W) S Series
SD1VW006FNJW 006 F - 2 positions, Spring offset in position b, operated in position 0 N - NBR 24 VDC Connector as per EN 175301-803, solenoid identification as per ISO 9461 (code W) S Series
SD1VW006KVTW 006 K - 2 positions, spring offset in position 0, operated in position b V - FKM 230V 50Hz / 240V 60Hz Connector as per EN 175301-803, solenoid identification as per ISO 9461 (code W) S Series
SD1VW007CNJW 007 C - 3 positions, spring offset in position 0, operated in position a or b N - NBR 24 VDC Connector as per EN 175301-803, solenoid identification as per ISO 9461 (code W) S Series
SD1VW007CNTW 007 C - 3 positions, spring offset in position 0, operated in position a or b N - NBR 230V 50Hz / 240V 60Hz Connector as per EN 175301-803, solenoid identification as per ISO 9461 (code W) S Series
SD1VW007CNYW 007 C - 3 positions, spring offset in position 0, operated in position a or b N - NBR 110V 50 Hz / 120V 60 Hz Connector as per EN 175301-803, solenoid identification as per ISO 9461 (code W) S Series
SD1VW007ENJW 007 E - 2 positions, spring offset in position 0, operated in position a N - NBR 24 VDC Connector as per EN 175301-803, solenoid identification as per ISO 9461 (code W) S Series
SD1VW008ENTW 008 E - 2 positions, spring offset in position 0, operated in position a N - NBR 230V 50Hz / 240V 60Hz Connector as per EN 175301-803, solenoid identification as per ISO 9461 (code W) S Series
SD1VW008EVTW 008 E - 2 positions, spring offset in position 0, operated in position a V - FKM 230V 50Hz / 240V 60Hz Connector as per EN 175301-803, solenoid identification as per ISO 9461 (code W) S Series
SD1VW009CNTW 009 C - 3 positions, spring offset in position 0, operated in position a or b N - NBR 230V 50Hz / 240V 60Hz Connector as per EN 175301-803, solenoid identification as per ISO 9461 (code W) S Series
SD1VW009CNYW 009 C - 3 positions, spring offset in position 0, operated in position a or b N - NBR 110V 50 Hz / 120V 60 Hz Connector as per EN 175301-803, solenoid identification as per ISO 9461 (code W) S Series
SD1VW009CVTW 009 C - 3 positions, spring offset in position 0, operated in position a or b V - FKM 230V 50Hz / 240V 60Hz Connector as per EN 175301-803, solenoid identification as per ISO 9461 (code W) S Series
SD1VW009ENJW 009 E - 2 positions, spring offset in position 0, operated in position a N - NBR 24 VDC Connector as per EN 175301-803, solenoid identification as per ISO 9461 (code W) S Series
SD1VW009ENKW 009 E - 2 positions, spring offset in position 0, operated in position a N - NBR 12 VDC Connector as per EN 175301-803, solenoid identification as per ISO 9461 (code W) S Series
SD1VW010CNTW 010 C - 3 positions, spring offset in position 0, operated in position a or b N - NBR 230V 50Hz / 240V 60Hz Connector as per EN 175301-803, solenoid identification as per ISO 9461 (code W) S Series
SD1VW010CVTW 010 C - 3 positions, spring offset in position 0, operated in position a or b V - FKM 230V 50Hz / 240V 60Hz Connector as per EN 175301-803, solenoid identification as per ISO 9461 (code W) S Series
SD1VW010KNJW 010 K - 2 positions, spring offset in position 0, operated in position b N - NBR 24 VDC Connector as per EN 175301-803, solenoid identification as per ISO 9461 (code W) S Series
SD1VW011CNTW 011 C - 3 positions, spring offset in position 0, operated in position a or b N - NBR 230V 50Hz / 240V 60Hz Connector as per EN 175301-803, solenoid identification as per ISO 9461 (code W) S Series
SD1VW011CNYW 011 C - 3 positions, spring offset in position 0, operated in position a or b N - NBR 110V 50 Hz / 120V 60 Hz Connector as per EN 175301-803, solenoid identification as per ISO 9461 (code W) S Series
SD1VW014CNJW 014 C - 3 positions, spring offset in position 0, operated in position a or b N - NBR 24 VDC Connector as per EN 175301-803, solenoid identification as per ISO 9461 (code W) S Series
SD1VW014CNKW 014 C - 3 positions, spring offset in position 0, operated in position a or b N - NBR 12 VDC Connector as per EN 175301-803, solenoid identification as per ISO 9461 (code W) S Series
SD1VW014CNTW 014 C - 3 positions, spring offset in position 0, operated in position a or b N - NBR 230V 50Hz / 240V 60Hz Connector as per EN 175301-803, solenoid identification as per ISO 9461 (code W) S Series
SD1VW014CNYW 014 C - 3 positions, spring offset in position 0, operated in position a or b N - NBR 110V 50 Hz / 120V 60 Hz Connector as per EN 175301-803, solenoid identification as per ISO 9461 (code W) S Series
SD1VW014ENJW 014 E - 2 positions, spring offset in position 0, operated in position a N - NBR 24 VDC Connector as per EN 175301-803, solenoid identification as per ISO 9461 (code W) S Series
SD1VW014ENTW 014 E - 2 positions, spring offset in position 0, operated in position a N - NBR 230V 50Hz / 240V 60Hz Connector as per EN 175301-803, solenoid identification as per ISO 9461 (code W) S Series
SD1VW014EVJW 014 E - 2 positions, spring offset in position 0, operated in position a V - FKM 24 VDC Connector as per EN 175301-803, solenoid identification as per ISO 9461 (code W) S Series
SD1VW014EVTW 014 E - 2 positions, spring offset in position 0, operated in position a V - FKM 230V 50Hz / 240V 60Hz Connector as per EN 175301-803, solenoid identification as per ISO 9461 (code W) S Series
SD1VW015CNTW 015 C - 3 positions, spring offset in position 0, operated in position a or b N - NBR 230V 50Hz / 240V 60Hz Connector as per EN 175301-803, solenoid identification as per ISO 9461 (code W) S Series
SD1VW015ENJW 015 E - 2 positions, spring offset in position 0, operated in position a N - NBR 24 VDC Connector as per EN 175301-803, solenoid identification as per ISO 9461 (code W) S Series
SD1VW015ENTW 015 E - 2 positions, spring offset in position 0, operated in position a N - NBR 230V 50Hz / 240V 60Hz Connector as per EN 175301-803, solenoid identification as per ISO 9461 (code W) S Series
SD1VW015EVJW 015 E - 2 positions, spring offset in position 0, operated in position a V - FKM 24 VDC Connector as per EN 175301-803, solenoid identification as per ISO 9461 (code W) S Series
SD1VW015EVTW 015 E - 2 positions, spring offset in position 0, operated in position a V - FKM 230V 50Hz / 240V 60Hz Connector as per EN 175301-803, solenoid identification as per ISO 9461 (code W) S Series
SD1VW016KNJW 016 K - 2 positions, spring offset in position 0, operated in position b N - NBR 24 VDC Connector as per EN 175301-803, solenoid identification as per ISO 9461 (code W) S Series
SD1VW020BNJJ 020 B - 2 positions, spring offset in position b, operated in position a N - NBR 24 VDC Connector as DT04-2P “Deutsch" (code J) S Series
SD1VW020HNJJ 020 H - 2 positions, spring offset in position a, operated in position b N - NBR 24 VDC Connector as DT04-2P “Deutsch" (code J) S Series
SD1VW020HNKW 020 H - 2 positions, spring offset in position a, operated in position b N - NBR 12 VDC Connector as per EN 175301-803, solenoid identification as per ISO 9461 (code W) S Series
SD1VW021CNJW 021 C - 3 positions, spring offset in position 0, operated in position a or b N - NBR 24 VDC Connector as per EN 175301-803, solenoid identification as per ISO 9461 (code W) S Series
SD1VW021CNTW 021 C - 3 positions, spring offset in position 0, operated in position a or b N - NBR 230V 50Hz / 240V 60Hz Connector as per EN 175301-803, solenoid identification as per ISO 9461 (code W) S Series
SD1VW021CVTW 021 C - 3 positions, spring offset in position 0, operated in position a or b V - FKM 230V 50Hz / 240V 60Hz Connector as per EN 175301-803, solenoid identification as per ISO 9461 (code W) S Series
SD1VW022CNTW 022 C - 3 positions, spring offset in position 0, operated in position a or b N - NBR 230V 50Hz / 240V 60Hz Connector as per EN 175301-803, solenoid identification as per ISO 9461 (code W) S Series
SD1VW022ENJW 022 E - 2 positions, spring offset in position 0, operated in position a N - NBR 24 VDC Connector as per EN 175301-803, solenoid identification as per ISO 9461 (code W) S Series
SD1VW022ENTW 022 E - 2 positions, spring offset in position 0, operated in position a N - NBR 230V 50Hz / 240V 60Hz Connector as per EN 175301-803, solenoid identification as per ISO 9461 (code W) S Series
SD1VW026BNTW 026 B - 2 positions, spring offset in position b, operated in position a N - NBR 230V 50Hz / 240V 60Hz Connector as per EN 175301-803, solenoid identification as per ISO 9461 (code W) S Series
SD1VW026HNKW 026 H - 2 positions, spring offset in position a, operated in position b N - NBR 12 VDC Connector as per EN 175301-803, solenoid identification as per ISO 9461 (code W) S Series
SD1VW026HNTW 026 H - 2 positions, spring offset in position a, operated in position b N - NBR 230V 50Hz / 240V 60Hz Connector as per EN 175301-803, solenoid identification as per ISO 9461 (code W) S Series
SD1VW030BNKW 030 B - 2 positions, spring offset in position b, operated in position a N - NBR 12 VDC Connector as per EN 175301-803, solenoid identification as per ISO 9461 (code W) S Series
SD1VW030DNJW 030 D - 2 positions, operated in position a or b, no center or offset position N - NBR 24 VDC Connector as per EN 175301-803, solenoid identification as per ISO 9461 (code W) S Series
SD1VW030DNTW 030 D - 2 positions, operated in position a or b, no center or offset position N - NBR 230V 50Hz / 240V 60Hz Connector as per EN 175301-803, solenoid identification as per ISO 9461 (code W) S Series
SD1VW030DVJW 030 D - 2 positions, operated in position a or b, no center or offset position V - FKM 24 VDC Connector as per EN 175301-803, solenoid identification as per ISO 9461 (code W) S Series
SD1VW030DVTW 030 D - 2 positions, operated in position a or b, no center or offset position V - FKM 230V 50Hz / 240V 60Hz Connector as per EN 175301-803, solenoid identification as per ISO 9461 (code W) S Series
SD1VW030HNKW 030 H - 2 positions, spring offset in position a, operated in position b N - NBR 12 VDC Connector as per EN 175301-803, solenoid identification as per ISO 9461 (code W) S Series
SD1VW030HNTW 030 H - 2 positions, spring offset in position a, operated in position b N - NBR 230V 50Hz / 240V 60Hz Connector as per EN 175301-803, solenoid identification as per ISO 9461 (code W) S Series
SD1VW083BNJW 083 B - 2 positions, spring offset in position b, operated in position a N - NBR 24 VDC Connector as per EN 175301-803, solenoid identification as per ISO 9461 (code W) S Series

Recommended

Close [ x ]
Full Screen
687PDC
K38849
